This 6-way power divider , in frequencies from 9 GHz to 10 GHz, offers many features including: high isolation and low insertion loss.
All of our products are fully customizable, including high power and broadband design.
You could contact us by info1@raytheosmicrowave.com or zxx6786@gmail.com.
Frequency Range | 9-10 GHz |
---|---|
Insertion Loss | ≤ 1.2 dB |
VSWR | ≤ 1.4 |
Amplitude Balance | ≤1 dB |
Phase Balance | ≤10 degree |
Power Handling | 10 W (CW) |
Surface Finish | Shave putty, and gray paint |
Isolation | ≥16 dB |
Frequency Range: 9-10 GHz
Insertion Loss (dB) : ≤ 1.2 dB
VSWR (Main line): ≤ 1.4
Isolation: ≥16 dB
Amplitude Balance: ≤1 dB
Phase Balance:≤10 degree
Power Handling: 10 W (CW)
RF Connector : SMA – K
Surface Finish: Shave putty, and gray paint
More details in Datasheet, Please download 3 datasheet of 6-way power combiner(RYT-A063022)-1
