This LC band pass filter is designed to handle up to 100 watts ,with low insertion loss and high rejection.
All of our products are fully customizable, including difficult indicators and demanding environmental requirements
You could contact us by info1@raytheosmicrowave.com or zxx6786@gmail.com
| Frequency Range | 1~1.8 GHz |
|---|---|
| RF connector | SMA – K |
| Insertion Loss | 0.8 dB Max |
| Pass Band Ripple | ≤±0.25 dB |
| Rejection | ≥45dB@2000-3200MHz |
| VSWR | ≤ 1.5 |
| Surface Finish | Silver Plated |
Frequency Range : 1000-1800MHz
RF Connectors: SMA – K
Insertion Loss (dB): ≤0.8 dB
Pass Band Ripple (dB): ≤±0.25 dB
Rejection: ≥45dB@2000-3200MHz
VSWR: ≤1.5
Surface Finish: Silver Plated
Impedance: 50 Ω
Power Handling(W): 100W
More details in Datasheet, Please download 2Datasheet of LC band pass&high power filter (RYTLPF1G-1.8G-100W)
